Molded Case Circuit Breaker L568
Sale price
$21.95
Regular price $102.40
Skip to product information
MOLDED CASE, FIXED THERMAL FIXED MAGNETIC TYPE; 2 INCH WIDTH X 2.99 INCH DEPTH X 5.5 INCH HEIGHT SIZE; 690 MAX. AC VOLTAGE RATING; 250 MAX. DC VOLTAGE RATING; UL, CSA, CE APPROVAL; 240/480/600 VAC AT 50/60 HZ, 125/250 VDC (UL/CSA/NEMA); 220 TO 240/380 TO 415/600 TO 690 VAC AT 50/60 HZ, 125/250 VDC (IEC) VOLTAGE RATING; 35 KILOAMPERE AT 240 VAC, 25 KILOAMPERE AT 480 VAC, 18 KILOAMPERE AT 600 VAC, 10 KILOAMPERE AT 125/250 VDC (UL/CSA/NEMA); 35 KILOAMPERE AT 220 TO 240 VAC, 25 KILOAMPERE AT 380 TO 415 VAC, 3 KILOAMPERE AT 600/690 VAC, 10 KILOAMPERE AT 125/250 VDC (IEC) INTERRUPTING RATING; 15 AMPERE AT 40 DEGREE CELSIUS CURRENT RATING; 2 POLE(S); ALUMINUM/COPPER STANDARD PRESSURE LINE AND LOAD TERMINAL TERMINAL TYPE; EG FRAME TYPE; CUTLER-HAMMER[R] BRAND; EGE MODEL CHL EGE2015FFG 2P 15A CIRCUIT BREAKER
Molded Case Circuit Breaker L568
Sale price
$21.95
Regular price $102.40
Shipping calculated at checkout.
